Features:

·         96KHz sampling frequency, 32-bit DSP processor, 24-bit A/D and D/A converter.

·         Selectable audio signal input one from four, each analog audio signal input sensitivity can be selected providing three groups of Mics input, standard 5.1 sound channel output.

·         Provide USB port, WIFI or wired network port are connected to PC by externally connecting to WIFI controller （TS-880SU）with serial port to remotely control and infrared control .

·         Directly to use the function keys on front panel or Connecting with PC to operate the device.

·         Rotate the knob on the front panel directly, can control the mic volume, effect volume, music volume, master volume.

·         A single unit provides 20 groups devices data storage, provides 10 groups effect data storage, can be replicated between devices by PC software.

·         User can set the password to limit the parts or whole functions by the "system" key on the panel, avoid non-workers' operation to damage the machine's working status.

·         Using character LCD screen and 6-segment LED displaying input / output precision digital level meter, mute and edit state.

·         Each input/output both delay and phase control and mute settings, input delay of up to 30ms, the output delay of up to 60ms.

·         The output channel also can control the effect ratio of the channel, mic volume, music volume and effect volumes.

·         Effect with three-band parametric equalizer, and 1 pair high and low pass filter, Echo and effects specific parameters can be adjusted.

·         User can control the main parameters of the channel through the S terminal connection to the matrix.

·         Microphone with four levels of anti-whistle function.
